Model
DPS-300K / DPS-400K / DPS-500K / DPS-600K DPS-800K / DPS-1000K / DPS-1200K
Power Rating
DPS-300K
DPS-400K
DPS-500K
DPS-600K
DPS-800K
DPS-1000K
DPS-1200K
300 kVA / 300 kW
400 kVA / 400 kW
500 kVA / 500 kW
600 kVA / 600 kW
800 kVA / 800 kW
1000 kVA / 1000 kW
1200 kVA / 1200 kW
Input
Nominal Voltage
Voltage Range
Current Harmonic Distortion
Power Factor
Frequency Range
220/380 Vac, 230/400 Vac, 240/415 Vac (3-phase, 4-wire + G)
176/304~276/478 Vac (full load)
< 3% (with Full Linear Load)
< 5% (with Full Non-linear Load)
> 0.99
40~70 Hz
Output
Voltage
Voltage Harmonic Distortion
Voltage Regulation
Output Power Factor
Frequency
Overload Capability
220/380 Vac, 230/400 Vac, 240/415 Vac (3-phase, 4-wire + G)
< 1.5% (Linear Load)
< 5% (Non-linear Load)
± 1% (static), ± 5% (dynamic)
1
50/60 Hz (Auto-Selectable)
≤ 125%: 10 min
≤ 150%: 1 min
>150%: 1 sec
Display
10” Color Touch Panel
Interface
Standard
Optional
RS232, Parallel port, USB, Modbus RS485, Input dry contact, Output dry contact, SNMP card inbuilt in touch screen
Relay I/O card, Battery cabinet temperature sensor cable
Conformance
Safety: CE
Efficiency
AC-AC
ECO Mode
Up to 96.5%
99%
Battery
Type
Charge Current
DPS-300K
DPS-400K
DPS-500K
DPS-600K
DPS-800K
DPS-1000K
DPS-1200K
Battery Quantity
VRLA, LiB
90 A
120 A
150 A
180 A
240 A
300 A
360 A
30~46 pcs
Environment
Operating Temperature
Relative Humidity
Audible Noise
IP Protection
0~40℃
0~95% (non-condensing)
< 80 dB
IP20
Others
Parallel Redundancy and Expansion
Emergency Power Off
Maximum 8 units
Remote and local
Physical
Dimensions (W x D x H)
DPS-300K
DPS-400K/500K/600K
DPS-800K
DPS-1000K/1200K
Weight
DPS-300K
DPS-400K
DPS-500K
DPS-600K
DPS-800K
DPS-1000K
DPS-1200K
600* x 900 x 2000 mm
1200* x 900 x 2000 mm
1800 x 900 x 2000 mm
2450 x 900 x 2000 mm
515 kg
700 kg
811 kg
970 kg
1270 kg
1850 kg
2000 kg
* The width is for the cabinet which has four inbuilt switches.
* For DPS-300K, only top cable entry is available
All specifications are subject to change without prior notice.
